Achieve Precision and Versatility with UCAM’s Compact Tilting Rotary Table USSR 200q TN

In today’s high-precision machining landscape, space, flexibility, and reliability are crucial. UCAM’s most compact tilting rotary table, the USSR 200q TN, is engineered to meet these demands, delivering exceptional performance even in space-constrained setups.

Recently, the USSR 200q was seamlessly integrated into a Mazak machine using UCAM’s in-house controller and servo solutions, enabling 4+1 axis machining with unmatched accuracy.

Key Features of the USSR 200q TN

Designed for versatility and precision, the USSR 200q TN combines robust engineering with a user-friendly design:

Compact & Lightweight Design: Ideal for setups where space is limited, without compromising on performance.
Easy Installation: Streamlined integration allows faster deployment, saving valuable production time.
Pneumatic & Hydraulic Clamping: Flexible clamping options cater to diverse machining applications.
Ready-to-Fit Rotary Union: Ensures seamless connectivity for tooling and utilities.
Robust Tilt Axis: Maintains stability and precision, even during complex machining operations.

Whether you’re tackling intricate 4+1-axis parts or optimizing production in constrained environments, the USSR 200q provides precision, reliability, and adaptability in one compact solution.

Discover how UCAM rotary solutions can elevate your machining capabilities. Contact us to learn more.

FAQs

What are the benefits of a compact CNC Tilting Rotary Table?

A compact tilting rotary table like the UCAM USSR 200q TN allows machine shops to achieve high-precision 4+1 axis machining in space-constrained setups. Its lightweight footprint maximizes the CNC machining envelope without sacrificing rigidity or performance.

Can UCAM Rotary Tables be integrated into existing CNC machines?

Yes. UCAM rotary tables are designed for seamless integration into major machine brands, such as Mazak. Using UCAM’s in-house controllers and servo solutions, deployment is fast and streamlined, instantly upgrading standard machines to multi-axis capabilities.

What clamping options does the UCAM USSR 200q TN offer?

The USSR 200q TN features flexible pneumatic and hydraulic clamping options. This ensures a highly robust tilt axis and maximum stability during complex machining operations, providing reliable precision across a wide variety of manufacturing applications.
