Product specification
CNC Rotary Table
-
URQ 180
Compact and lightweight design delivering 300 Nm pneumatic clamping and 250 kg horizontal capacity for efficient, small-component machining.
-
URQ 180
Advanced compact solution for space-constrained setups, featuring 500 Nm hydraulic clamping and a 250 kg horizontal load capacity
-
URQ 200HS
Advanced high-speed indexing solution featuring 900 Nm hydraulic clamping and a 250 kg capacity for precise, efficient component profiling.
-
URQ 200HS
Precision-built for tight machine envelopes, this high-speed indexing table offers 900 Nm hydraulic clamping and 250 kg load support.
-
URQ 250HS
Engineered for rapid high-speed indexing, featuring a 400 kg horizontal capacity and exceptional positioning accuracy for optimized cycle times.
-
URQ 250HS
Precision-built for high-speed indexing in tight workspaces, offering 1,100 Nm hydraulic clamping and a 350 kg horizontal capacity
-
URX 320
Optimized for medium-duty versatility, delivering a 600 kg horizontal capacity and 1,700 Nm hydraulic clamping for automotive and general engineering
-
URX 320
Optimized for medium-duty versatility, managing 600 kg horizontal loads with 1,700 Nm hydraulic clamping and rigid through-bore capability.
-
URX 320
Optimized with rear-motor mounting to maximize table travel, managing 600 kg payloads and 1,700 Nm hydraulic clamping torque.
-
URH 401
Precision-built for strength and stability, managing 750 kg horizontal loads with 2,000 Nm hydraulic clamping and high driving torque
-
URH 401
High-performance rigid design optimized for heavy loads, providing 2,000 Nm hydraulic clamping and a 750 kg horizontal capacity
-
URH 500
Engineered for heavy-duty strength, supporting 900 kg horizontal loads with 2,750 Nm hydraulic clamping for reliable large-component machining.
-
URH 500
Engineered for demanding high-volume operations, featuring a 900 kg load capacity and 2,750 Nm hydraulic clamping for heavy-duty performance
-
URH 631
Robust heavy-duty solution supporting 1,500 kg horizontal loads with 3,500 Nm hydraulic clamping for high-torque industrial milling.
-
URH 631
Advanced rigid architecture engineered for extreme cutting loads, supporting 1,500 kg horizontal workpieces with 3,500 Nm hydraulic clamping torque
Product Layout & SpecCNC Rotary Production System
-
URPQ 200 HS
Optimized for high-volume efficiency, this production system provides rapid indexing and a modular design to streamline complex manufacturing workflows.
-
URPQ 250 HS
High-performance modular production solution delivering quick set-up changes and increased clamping torque for high-volume manufacturing environments.
-
URPX 320
Delivering superior rigid construction and higher work inertia, this system manages 600 kg payloads for demanding industrial production lines.
Multi Spindle Rotary Table
-
URH 125-2S
Productive dual-spindle design optimized for high-volume automated lines, increasing throughput with simultaneous multi-part machining.
-
URH 125-3S
High-performance three-spindle design for simultaneous high-volume production, maximizing throughput with a compact, rigid modular construction
-
URH 170-2S
High-productivity dual-spindle design for enhanced throughput, featuring a modular structure and 400 Nm hydraulic clamping for high-volume machining
-
URH 170-3S
Precision-built three-spindle system delivering superior rigidity for multi-part machining, supported by 400 Nm hydraulic clamping torque.
-
URH 170-4S
High-productivity four-spindle design optimized for high-volume tapping and machining, maximizing throughput within a compact, modular workspace.
Large Bore Rotary Table
-
ULBQ 250
High-speed indexing solution featuring a Ø80 mm through-bore and 450 Nm pneumatic clamping, designed for rapid processing of hollow components.
-
ULBQ 250
High-velocity indexing table with a Ø80 mm through-bore and 450 Nm pneumatic clamping, perfect for restricted-space automation.
-
ULBR 320
Engineered with an expansive Ø110 mm through-bore, this solution enables efficient machining of oversized shafts and long cylindrical components.
-
ULBR 320
Delivering exceptional throughput for oversized components, this large-bore solution features a Ø110 mm through-hole and 1,100 Nm hydraulic clamping
-
ULBR 400
Strategic large-bore design featuring a Ø160 mm through-hole and 2,500 Nm hydraulic clamping for accessible heavy-duty machining.
-
ULBR 500
Optimized for the power generation industry, featuring a Ø200 mm through-bore and 4,000 Nm clamping for maximum operational stability.
-
ULBR 630
Engineered for complex setups, this Ø260 mm large-bore table delivers 6,000 Nm hydraulic clamping and 1,300 kg horizontal load capacity.
Rotary Table for Horizontal Application
-
URH Ø800RH
Optimized for medium-to-large horizontal machining, delivering a 7,000 kg load capacity and reliable 12,000 Nm hydraulic clamping torque
-
URH SQ800RH
Precision-built with a robust square tabletop, managing 7,000 kg horizontal loads and 12,000 Nm clamping for extreme cutting stability
-
URL Ø1000RH
Engineered for large-scale production, managing 6,800 kg horizontal payloads with 12,000 Nm hydraulic clamping and high-driving torque
-
URL SQ1000RH
Magnificent square-tabletop design for massive workpieces, managing 6,800 kg loads with 12,000 Nm hydraulic clamping for industrial stability.
-
URH Ø1200RH
Engineered for large-scale production, managing 12,500 kg horizontal payloads with 25,000 Nm hydraulic clamping and high-driving torque
-
URH SQ1200RH
Exceptional large-scale square tabletop handling 12,500 kg horizontal loads with 25,000 Nm hydraulic clamping for maximum cutting stability.
-
URL Ø1600RH
Advanced positioning solution for heavy-duty machining with a 10,000 kg load capacity and 25,000 Nm clamping torque
-
URL SQ1600RH
Optimized for massive components, this square-tabletop solution supports 10,000 kg horizontal loads with 25,000 Nm hydraulic clamping torque
Rotary Table for Vertical Application
-
ULBR 800-RH
Precision-built for oil and gas applications, featuring a massive Ø260 mm large bore and 6,000 Nm hydraulic clamping torque.
-
ULBR 1000-RH
Engineered for superior precision in vertical applications, featuring a massive Ø500 mm large bore and 10,000 Nm hydraulic clamping
-
ULBR 1200-RH
Powerful vertical solution featuring a massive Ø500 mm through-bore and 10,000 Nm hydraulic clamping for large-scale energy sector components.
-
URV 800-RH
Advanced vertical solution for heavy-duty applications, supporting 3,000 kg loads with 6,000 Nm hydraulic clamping and rigid through-hole capability
-
URV 1000-RH
Superior vertical machining platform supporting 4,500 kg loads with 10,000 Nm hydraulic clamping for high-precision mining and engine parts.
CNC Tilting Rotary Tables
-
USSR 150q TN
Advanced compact 5-axis solution featuring 300 Nm hydraulic clamping and precision indexing for small, intricate medical and aerospace parts.
-
USSR-200q TN
Delivering robust stability for 5-axis operations, this compact tilting solution features 850 Nm hydraulic clamping and high-rigidity dynamics.
-
ULSR 200q TN
High-rigidity 5-axis tilting mechanism providing a larger working volume and 850 Nm clamping torque for diverse precision applications.
-
USSR 250q TN
Forceful 5-axis tilting solution delivering high driving torque and 1,200 Nm hydraulic clamping for large, complex component profiles.
CNC Large Bore Tilting Rotary Tables
-
URH 320TN
Precision-engineered with a large tabletop and Ø100 mm bore, facilitating complex 5-axis machining for the aerospace and automotive sectors.
-
ULBR 320-TN
Robust 5-axis tilting platform with a Ø110 mm through-bore and 1,250 Nm clamping torque, providing exceptional flexibility for intricate setups.
-
ULBR 400-TN
Advanced tilting solution featuring a Ø160 mm through-bore and 2,500 Nm hydraulic clamping, optimized for large-diameter workpiece accessibility.
CNC Deep Tilting Rotary Tables
-
URH 320-DT
Engineered for extreme angular reach, this deep-tilting model supports 320 kg loads with a Ø100 mm bore and 2,500 Nm clamping.
-
URH 400-DT
Deep-tilting 5-axis architecture providing an expansive working volume for 400 kg payloads and 4,000 Nm hydraulic clamping torque.
-
URH 500-DT
Delivering an expanded work envelope for heavy-duty 5-axis machining, with a 400 kg capacity and 5,000 Nm tilting torque
Direct Drive Rotary Table
-
UDDR200R-50P
Delivering exceptional high-speed indexing and zero backlash, this compact 4th-axis solution features a 400 Nm pneumatic clamping system
